HDMI over CAT6/7 Extender with PoC - 197 ft (60m)
Model:UF-HDE60T
► Support video resolutions up to 1080P@60Hz
► Extend HDMI signal over single UTP CAT6/6a/7 cable up to 60m
► Supports Power over Cable (PoC) from Transmitter to Receiver
This HDMI Extender includes a transmitter unit (TX) and a receiver unit (RX), working as a pair. It allows for transmission and extension uncompressed full HD 1080p@60Hz HDMI signal via CAT6/6A/7 network cable, the transmission distance is up to 60 meters with zero latency. At the same time, the signal is stable, and the built-in EDID greatly improves the compatibility of the device. It is automatic adjust a needed Monitor or distance, also it supports PoC to power the receiver (Connect power supply to the transmitter unit only, each unit will power up, as the Receiver unit is powered by the Transmitter unit through network cable). This product is perfect for AV transmission in applications of HD conference system, HD video shooting, HD multimedia education system, HD digital advertising and signage etc.
► Uncompressed and zero latency
► Auto adjustment to match the cable length
► Support video resolutions up to 1080P@60Hz
► Extend HDMI signal over single UTP CAT6/6a/7 cable up to 60m
► Support EDID pass-through for smart match between the source device and display device
► Supports Power over Cable (PoC) from Transmitter to Receiver;
► ESD electrostatic protection; support hot plug, plug and play, easy to install
|
Video |
|
|
HDMI Compliance: |
HDMI 1.3 |
|
HDCP Compliance: |
HDCP 1.3 |
|
Maximum Pixel Clock: |
165MHz Digital |
|
Maximum Data Rate: |
6.75 Gbps |
|
Resolution: |
3D:1080p@60Hz; 1080i@50/60Hz, 720p@50/60Hz, 576i@50Hz, 576p@50Hz, 480i@60Hz, 480p@60Hz |
|
Color Space: |
RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
|
Color Depth: |
10-bit, 12-bit |
|
Audio Formats: |
PCM 2CH, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby Digital+ |
|
ESD Protection: |
Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge) |
|
Impedance: |
100Ω |
|
Connector: |
HDMI-A [19-pin female] |
|
HDMI Cable: |
Less than 5m at 1080p@60hz |
|
UTP |
|
|
Interface: |
RJ45 (IEEE - 568b connectioN) |
|
Transmission Distance: |
CAT6/7--- 60m at 1080p@60hz NOTE: Distance depends on the characteristics and quality of the cables and the type of HDMI source and display. Higher resolutions and longer transmission distances require low-skew cables (<25 ns/100 m) for best performance. We recommend using unshielded solid core CAT6/7 cable. |
|
Network Cable: |
Low resistance and consumption oxygen-free copper core (CAT6, CAT6A or CAT7)-UTP |
|
Environmental |
|
|
Operating Temperature: |
-5°C to 70°C (23°F to 158°F) |
|
Storage Temperature: |
-40°C to 80°C (-40°F to 176°F) |
|
Relative Humidity: |
5% to 95% non-condensing |
|
Storage Humidity: |
5% to 95% non-condensing |
|
Electrical and Mechanical |
|
|
Input Power: |
5V DC, 1A max. |
|
Power Consumption: |
3W max. |
|
LED Indicators |
|
|
PWR: |
Power Status |
|
STA: |
Signal Status |
|
Dimensions (WxDxH): |
79 x 43 x 23mm (3.11' 'x 1.69'' x 0.9'') |
|
Weight: |
0.5KG |
|
Casing: |
Metal Case |
|
Mounting Options: |
Desktop, Wall Mount |
|
Regulatory Approvals |
|
|
CE, RoHS, FCC |
|
- Download FileName：UF-HDE60T HDMI over CAT6,7 Extender with PoC 60m Datasheet V1.0.pdf Size： 690KB
|
Model |
Description |
|
UF-HDE60 |
HDMI Over CAT5/CAT6 Extender with Power Over Cable - 197 ft (60m), including 1 Transmitter & 1 Receiver, used by pairs |
