Ethernet

Standards:

IEEE 802.3an 10GBASE-T

IEEE 802.3ae 10Gbps Ethernet

IEEE 802.3z 10GBASE-SX/LX

IEEE802.3x Flow control

IEEE802.1q VLAN

IEEE802.1p QoS

IEEE802.1d Spanning Tree

Processing Type:

Store and Forward

Fabric:

20Gbps

MAC Table Size:

2K

Jumbo Frame:

16K

Buffer Space:

1Mbit

Transmission mode:

full-duplex / half-duplex adaptive

Time Delay:

＜20μs

Network Cables:

10GBASE-T:

 10G--Cat 6A/Cat 7

 Cat 5/5e/6/6A/7 UTP cable (100 meters, max.)

 EIA/TIA-568 100-ohm STP (100 meters, max.)

10GBASE-LR/SR/BX:

 50/125μm or 62.5/125μm multi-mode fiber optic cable, up to 300m

 9/125μm single-mode fiber optic cable, up to 80km

Connector:

1 x 10GBase-T RJ45

Optical Port:

1 x 10GBase-X SFP+

Environmental

Operating Temperature:

-10°C to 55°C

Storage Temperature:

-40°C to 70°C

Relative Humidity:

5% to 95% non-condensing

Storage Humidity:

5% to 95% non-condensing

Electrical and Mechanical

Input Power:

5-12V DC

Power Consumption:

3.75W

LED Indicators

PWR:

Power Status

10G:

10Gbps Speed Rate

FX Link/Act:

Fiber Link Status

SD:

Fiber Signal is detected

TX Link/Act:

Ethernet Link Status

Dimensions (WxDxH):

94 x 71 x 27mm

Weight:

180g (device only)

Casing:

Compact-sized metal case

Mounting Options:

Desktop, wall mountable

Media converter Chassis installation

Regulatory Approvals

CE, RoHS, FCC
