100Base-FX to 10/100Base-TX PoE+ Media Converter
Model:UF-1100P Series
► One 10/100Base-TX RJ45 port supporting a maximum distance of 100 m
► 100Base-FX SC (in default)/ST/FC (Optional) fiber port connects distances up to 120km
► Supports an IEEE 802.3at and IEEE 802.3af-compliant PoE device
The UF-1100P Series PoE+ Fast Ethernet Media Converter extends communication distance with high performance of data transmission via fiber optic cable. It is designed specially to satisfy the growing demand for higher power required network equipment such as network cameras, VOIP telephones, wireless LAN access points and other network devices that need higher power. Compliant to IEEE802.3af /at PoE standard, the PoE+ Fast Ethernet Media Converter is an ideal solution to deliver data and power network devices directly via the RJ45 interface without the need of installing extra power outlets and electrical cabling.
► One 10/100Base-TX RJ45 port supporting a maximum distance of 100 m
► 100Base-FX SC (in default)/ST/FC (Optional) fiber port connects distances up to 120km
► Supports an IEEE 802.3at and IEEE 802.3af-compliant PoE device (e.g., wireless access point, VoIP phone, IP camera, etc.)
► Provides power output up to 30 watts for one PoE-compliant device
► Supports full-duplex and half-duplex modes with auto-negotiation
► Status LEDs for power and Link/TX for both ports
► IP30 slim-type metal case
|
Ethernet |
|
|
Standards: |
IEEE 802.3, 10BASE-T |
|
IEEE 802.3u, 100BASE-TX |
|
|
IEEE 802.3u, 100BASE-FX |
|
|
IEEE 802.3x Full-duplex flow control |
|
|
Flow Control: |
Back pressure for half duplex |
|
IEEE 802.3x pause frame for full duplex |
|
|
Network Cables: |
Twisted-pair 10BASE-T: 2-pair UTP Cat. 3,4,5, up to 100m 100BASE-TX: 2-pair UTP Cat. 5, up to 100m Fiber-optic Cable 100BASE-FX: 50/125μm or 62.5/125μm multi-mode fiber cable for up to 2km (vary on 1x9 optical transceiver) 9/125μm single-mode cable for 25/40/60/120km (vary on 1x9 optical transceiver) |
|
Connector: |
1 x 10/100BASE-TX RJ45 |
|
Optical Port: |
1x 100Base-FX SC (in default)/ST/FC (Optional) |
|
Power over Ethernet |
|
|
PoE Standard |
IEEE 802.3at Power over Ethernet Plus standard IEEE 802.3af Power over Ethernet standard |
|
PoE Output |
IEEE 802.3af: PoE 48V DC, max. 15.4 watts, 350mA IEEE 802.3at: PoE 48~56V DC, max. 30 watts, 650mA |
|
Power Pin Assignment: |
1/2(+), 3/6(-) |
|
Environmental |
|
|
Operating Temperature: |
0°C to 55°C (32°F to 131°F) |
|
Storage Temperature: |
-10°C to 70°C (14°F to 158°F) |
|
Relative Humidity: |
5% to 95% non-condensing |
|
Storage Humidity: |
5% to 95% non-condensing |
|
Electrical and Mechanical |
|
|
Power Supply: |
52V DC, 0.58A external AC-to-DC adapter |
|
Power Consumption: |
4.6 watts (PoE not in use) 36W Max. (PoE in use) |
|
LED Indicators |
|
|
PWR: |
Power Status |
|
P1: |
PoE Power |
|
TP L/A |
Ethernet Link Status |
|
FX L/A |
Fiber Link Status |
|
DUP: |
Duplex Mode |
|
SPD: |
100M Ethernet Speed |
|
Dimensions (WxDxH): |
94 x 70 x 26mm (1.02''x 2.76''x 3.7'') |
|
Weight: |
200g (device only, not including power adapter & power cord) |
|
Casing: |
Compact-sized metal case |
|
Mounting Options: |
Desktop, wall mountable (wall-mount bracket not included) Media converter Chassis installation |
|
Regulatory Approvals |
|
|
CE, RoHS, FCC |
|
- Download FileName：UF-1100P 10100M PoE+ Media Converter Datasheet V1.0.pdf Size： 715KB
|
Model |
Description |
|
UF-1100P |
10/100BASE-TX to 100BASE-FX (SC, MM) PoE+ Media Converter -- 2km |
|
UF-1100PT |
10/100BASE-TX to 100BASE-FX (ST, MM) PoE+ Media Converter -- 2km |
|
UF-1100PF |
10/100BASE-TX to 100BASE-FX (FC, MM) PoE+ Media Converter -- 2km |
|
UF-1100P-25 |
10/100BASE-TX to 100BASE-FX (SC, SM) PoE+ Media Converter -- 25km |
|
UF-1100PT-25 |
10/100BASE-TX to 100BASE-FX (ST, SM) PoE+ Media Converter -- 25km |
|
UF-1100PF-25 |
10/100BASE-TX to 100BASE-FX (FC, SM) PoE+ Media Converter -- 25km |
|
UF-1100P-40 |
10/100BASE-TX to 100BASE-FX (SC, SM) PoE+ Media Converter -- 40km |
|
UF-1100P-80 |
10/100BASE-TX to 100BASE-FX (SC, SM) PoE+ Media Converter -- 80km |
|
UF-1100P-120 |
10/100BASE-TX to 100BASE-FX (SC, SM) PoE+ Media Converter -- 120km |
|
UF-1100PS-20A * |
10/100BASE-TX to 100BASE-FX (WDM TX:1310nm, SC, SM) PoE+ Media Converter -- 20km |
|
UF-1100PS-20B * |
10/100BASE-TX to 100BASE-FX (WDM TX:1550nm, SC, SM) PoE+ Media Converter -- 20km |
|
Remarks * |
UF-1100PS-20A and UF-1100PS-20B should run in pair. It means you must connect UF-1100PS-20A to one end while UF-1100S-20B to the other end. |
|
Mounting Options: |
► Desktop, wall mountable (wall-mount bracket not included) ►Media converter Chassis installation |
|
Power Options: |
► 52V DC, 0.58A external AC-to-DC adapter |
